Garrett GTD2263VZ 3.0 TDI Turbocharger Upgrade

NEW Garrett GTD2263VZ Turbocharger

This turbo is capable of around 350bhp when tuned. We would rate the stock GTD2060VZ to just over 300bhp

Increase in Performance

OEM Turbocharger Upgrade

Specs:

Turbo	Comp Ind -	Comp Exd -	Extended Tip -	Blades -	A.R -	Turbine In -	Turbine Ex
GTD2263VZ	44.5	63.1	66.9	6+6	54	50.1	42.9
GTD2060VZ	42.9	60	62.1	10	60	47	42.7

This turbo now includes the Turbo to MAF TIP Silicone to replace the stock item

This item will fit Vehicles with the following Engine Codes:

Audi A4 / Avant - Please confirm your vehicle details with us before purchasing

Audi A4 / S4 / Avant / quattro - Please confirm your vehicle details with us before purchasing

Audi A5 / S5 Coupe Sport - Please confirm your vehicle details with us before purchasing

Audi Q7 - Please confirm your vehicle details with us before purchasing

VW Amarok - Please confirm your vehicle details with us before purchasing

Audi A4 / Avant - CSWB (218) CRTC (272)

Audi A4 / S4 / Avant / quattro - CSWB (218) CRTC (272)

Audi A5 / S5 Coupe Sport - CSWB (218)

Audi A6 / Avant - CZVC (211) CZVD (211) CRTF (211) CZVA (218) CZVB (218) CRTE (218) CRTD (272)

Audi A6 / S6 / Avant / quattro - CZVC (211) CZVD (211) CRTF (211) CZVA (218) CZVB (218) CRTE (218) CRTD (272)

Audi A6 allroad quattro - CZVF (190) CZVC (211) CRTF (211) CRTE (218) CZVA (218) CRTD (272)

Audi A7 Sportback - CZVF (190) CZVD (211) CZVC (211) CRTF (211) CZVB (218) CZVA (218) CRTE (218) CRTD (272)

Audi Q7 - CRTE (218) CVMD (249) CUEA (258) CVZA (258) CRTC (272)

Audi A7 Sportback - CZVE (190)

VW Amarok - VW Amarok - DDXA (160) DDXB (201) DDXC (201) DDXE (258)

Replaces VW Part Numbers

059145873DB - 059145873 DB - 059 145 873 DB

059145873BE - 059145873 BE - 059 145 873 BE

059145873BJ - 059145873 BJ - 059 145 873 BJ

059145873BP - 059145873 BP - 059 145 873 BP

059145873CH - 059145873 CH - 059 145 873 CH

059145873CL - 059145873 CL - 059 145 873 CL

Modifications to the actuator on some models are required, this involves swapping the actuator and the modifications to the bracket/compressor housing to install correctly.

Tuning these vehicles with this turbo is critical and we highly advise someone experience with these carrying out the work. EMPs will need to be logged

The fitted speed sensor can be left unplugged and the compressor housing water ports left open
